VILLA-Square Adjustable 10W

VILLA-Square Adjustable 10W

videovideo

Products Specification:

Application: Recessed-mounted

SDCM: <3

Beam Angle: 15°, 24°, 38°

Power: 10W

CCT: 2700K, 3000K, 4000K

Line Drawing:

VILLA-Square Adjustable 10W

General Features:

Accessories

Secondary Reflector




VILLA-Square Adjustable

VILLA-Square Adjustable LED Downlight is outstanding for its elegant style and versatile application. Multi-head is available thanks to a smart mechanical design. The 355° rotation and 30 ° tilt makes it easy to be adjusted to specific angle with the precisely engineered adjustment mechanism. Different interchangeable color secondary reflectors meet both anti-glare and decorative function, and provide the maximum level of visual comfort.



 VILLA-Square Adjustable 10W

Precise Light Control

Four kinds of facial rings can be selected to create different light spot atmospheres and outstanding light shapes.

 VILLA-Square Adjustable 10W



Beam Angle

VILLA Downlight provides 15°, 24°, 38° beam angles for your choice. Anti-glare accessories can also be added for better visual comfort.


 VILLA-Square Adjustable 10W

High Visual Comfort

The glare-free angle ensures that there is no direct view of the LED and the visible part of the reflector produces practically no glare at all. This zone offers a high level of visual comfort.


 VILLA-Square Adjustable 10W

Modular Design

The modular design is achieved with LED module, mounting ring and secondary reflector. It’s easy to customize, manage stock, install and do maintenance, and easy to change the secondary reflector.


 VILLA-Square Adjustable 10W

DIY Your Own Light

Flexible head number combo (dual/triple/quadruple-head) is achievable with the smart downlight structure. Personalized and customized light fixtures can be achieved depending on the actual light-requiring setting and needs.

 VILLA-Square Adjustable 10W


Specs

-Elegant in its style, versatile in its using.

-Full range of adjustable downlight with wattages from 5W to 25W in 4 sizes.

-Easy to adjust to specific angle thanks to precision engineered adjustment mechanism.

-355° rotation and 30° tilt.

-Interchangeable different color secondary reflectors for anti-glare and decorative function.

-Anti-glare accessories provide maximum visual comfort.

Order info.PowerLed CurrentLuminous
Flux(lm)
CRICCTBeam Angle
(°)
VSA082-927N018W10W120mA547lm90+2700K18°
VSA082-927N024W10W120mA571lm90+2700K24°
VSA082-927N036W10W120mA537lm90+2700K36°
VSA082-02-927N018W10W×2250mA1143lm90+2700K18°
VSA082-02-927N024W10W×2250mA1183lm90+2700K24°
VSA082-02-927N036W10W×2250mA1148lm90+2700K36°



ImageDescriptionModel NO#Available for
VILLA-Square Adjustable 10WHoneycombVR075-HVSA082/TSA082
VSA082S/TSA082S
VILLA-Square Adjustable 10WFlood soft lightVR075-FVSA082/TSA082
VSA082S/TSA082S
VILLA-Square Adjustable 10WMdeium soft lightVR075-MVSA082/TSA082
VSA082S/TSA082S
VILLA-Square Adjustable 10WSquare lightVR075-SVSA082/TSA082
VSA082S/TSA082S
VILLA-Square Adjustable 10WRectangular lightVR075-RVSA082/TSA082
VSA082S/TSA082S


Downloads

Model Power Picture Download
Square-Adjustable 10W Square-Adjustable 10W Download
Model Power Picture Download
Square-Adjustable 10W Square-Adjustable 10W Download
Model Power Picture Download
VSA082 10W VSA082 CREE CRI90 3000K IESLDT
